High capacity and energy density
For providing stable power to devices, Panasonic NCR21700A 5000mAh 15A rechargeable battery offer 3.6V average operating voltage in order to guarantee maximum output power.
High discharge performance
Panasonic NCR21700A 5000mAh 15A battery provide powerful and constant power to the device or equipment, voltage drop less with load, the discharge curve is quiet stable from full to empty.
Applications widely
Panasonic NCR21700A 5000mAh 15A battery can be widely use to all products desire high capacity for longest running time. For example, Electric bikes, toys and electronics power devices.
Reliable and safe
Panasonic and Sanyo are world famous brand, also the leader of Li-ion 21700 battery technology, provide only reliable batteries, it is 100% safe by using the battery according to the cell datasheet.
| Items | Specifications | Notes |
| Nominal capacity | 5000mAh | Reference only |
| Nominal voltage | 3.6V | 1A discharge at 25°C |
| Nominal energy | 18Wh | Capacity(Ah) × Voltage(V) |
| Charging voltage | 4.20V | |
| Charging current | 1000mA 丨2500mA | Standard丨Rapid |
| Charging time | 6.0 hours 丨4.0 hours | Standard丨Rapid |
| Charging method | CC - CV | Constant current, constant voltage |
| Continuous discharge current | 1000mA 丨15A | Standard丨Maximum |
| Peak discharge current | 20A | Within a short time |
| Discharge end voltage | 2.5V | Discharge cut-off voltage |
| Dimensions | 21.1mm丨70.5mm | Diameter丨Height |
| Typical weight | 69g | 2.43 oz |
| Charge temperature range | +0 ~ +60°C | +50 ~ 110°F |
| Discharge temperature range | -10 ~ +45°C | -4 ~ +140°F |
| Storage temperature | -10 ~ +45°C | Within 3 months |
